Kauv raj tseem hu ua kauv steel yeeb nkab lossis kauv raj. Nws yog dov mus rau hauv ib lub raj pam ntawm lub kaum sab xis ntawm cov kauv kab (hu ua lub kaum sab xis pwm) ntawm cov hlau los yog cov hlau tsis tshua muaj hlau siv ntawm ib qho kev sib txuas ntawm cov hlua khi, thiab tom qab ntawd welded cov yeeb nkab seam, nws tuaj yeem tsim cov kav hlau loj nrog nqaim. steel hlau.
siv:
Cov kauv raj feem ntau yog siv rau kev thauj mus los ntawm cov roj thiab cov nkev roj, thiab nws cov lus qhia tshwj xeeb yog sawv cev los ntawm sab nraud * phab ntsa thickness. Yog hais tias lub kauv raj muaj ib leeg-sab vuam thiab ob-sided vuam, cov welded yeeb nkab yuav tsum xyuas kom meej cov hydraulic xeem, tensile lub zog ntawm vuam, thiab txias dabtsi yog khoov kev ua tau zoo.
Txheej txheem ntau lawm:
(1) Cov ntaub ntawv raw yog steel yob, welded hlau, thiab solder. Kev ntsuas lub cev thiab tshuaj lom neeg nruj yuav tsum dhau ua ntej kev nqis peev.
(2) Tig nrog steel taub hau thiab tails, siv ib leeg-silk los yog dual-xaim faus arc vuam, thiab siv tsis siv neeg faus arc vuam los ntxiv vuam tom qab dov rau hauv cov kav hlau.
(3) Ua ntej kev tsim, cov ntaub so ntswg yog ntshiab, txiav, thiab npaj, thiab qhov chaw yog ntxuav thiab thauj mus rau saum npoo.
(4) Siv lub ntsuas hluav taws xob txuas hluav taws xob los tswj lub siab ntawm lub tog raj kheej roj ntawm ob sab ntawm lub conveyor kom ntseeg tau tias kev thauj mus los zoo ntawm cov hlau.
(5) Sab nraud tswj lossis sab hauv tswj cov menyuam hom.
(6) Weld gap control device yog siv los xyuas kom meej tias qhov sib txawv weld ua tau raws li qhov xav tau ntawm vuam. Cov yeeb nkab txoj kab uas hla, qhov yuam kev ntug tus nqi thiab qhov sib txawv weld yog nruj me ntsis tswj.
(7) Internal vuam thiab sab nraud vuam siv nyob rau hauv lub tebchaws United States Lincoln vuam tshuab rau ib los yog ob tug hlau faus arc vuam kom tau ib tug ruaj khov vuam specification.
(8) Cov welded welded raug kuaj xyuas los ntawm kev raug mob tsis tu ncua ultrasonic tsis siv neeg nyob hauv online tsis tu ncua ultrasonic kev raug mob, kom ntseeg tau tias 100% ntawm cov kauv welded seams tsis puas ntsoog nrhiav kev pab. Yog tias muaj qhov tsis xws luag, cia li hu rau tub ceev xwm thiab tshuaj tsuag lub cim, cov neeg ua haujlwm tsim khoom kho cov txheej txheem tsis raug txhua lub sijhawm kom tshem tawm qhov tsis xws luag hauv lub sijhawm.
(9) Txiav cov yeeb nkab steel rau hauv ib lub hauv paus nrog cua plasma txiav tshuab.
(10) Tom qab txiav rau hauv ib lub yeeb nkab steel, txhua batch ntawm cov kav hlau yuav tsum tau ua nruj me ntsis kev soj ntsuam thawj zaug los xyuas cov khoom siv tshuaj, cov khoom xyaw tshuaj, cov khoom yaj, qhov zoo ntawm cov yeeb nkab steel, thiab tshuaj xyuas cov yeeb nkab steel. . Tom qab ntawd nws tuaj yeem raug muab tso rau hauv kev tsim khoom.
(11) Muaj ib feem ntawm lub suab nrov nruam nrhiav pom ntawm qhov vuam. Tom qab phau ntawv ultrasonic thiab X-ray tshuaj xyuas, yog tias muaj qhov tsis xws luag, tom qab kho, nws tsis raug kuaj dua kom txog thaum nws tau lees paub tias qhov tsis xws luag tau raug tshem tawm.
(12) Lub raj uas lub raj-hom pob qij txha uas cuam tshuam cov welded weld thiab cuam tshuam nrog cov kauv vuam yog txhua yam kuaj xyuas los ntawm X-ray TV lossis ua yeeb yaj kiab.
(13) Txhua cov yeeb nkab steel raug kuaj los ntawm cov dej zoo li qub, thiab lub siab yog sealing los ntawm radial foob. Kev ntsuas siab thiab lub sijhawm yog nruj me ntsis tswj los ntawm cov yeeb nkab steel hydraulic microcomputer nrhiav kom tau cov cuab yeej. Qhov ntsuas ntsuas tau raug luam tawm.
(14) Kev ua cov tshuab ua tiav ntawm qhov kawg ntawm cov raj xa dej, kom qhov kawg nto yog ntsug, thiab lub kaum sab xis ntawm lub taub hau thiab cov npoo npoo tau raug tswj kom raug.
